Welding Frame Light Round and Square LED Panel light

Product Introduction

Special body design, integrated the driver with the panel,easy to install and transport;The frame edge light has a high luminous efficiency.If the CRl is 80Ra, the luminous efficiency of luminaireis up to 115 Im/w. Special circuit design preventsdamage on one lamp from affecting the other lightsand overall lighting effect

Product Downloads

Overview

Picture	Product Name	Description	CCT(K)	POWER(W)	Certification & Warranty
	614*614MM Welding Frame Light	Product Size: 614x614x10 MM FRAME: White Diffuser: PC Driver:Customer provide Input Voltage: AC220-240V Ra: >80 Luminous Efficacy: 80lm/w PF: >0.9 Led: SMD2835 Led Quantity: 300 leds	3000K	38W	CE&Rohs 3 years YEARS
	595*595MM Welding Frame Light	Product Size: 595x595x10 MM FRAME: White Diffuser: PC Driver:Customer provide Input Voltage: AC220-240V Ra: >80 Luminous Efficacy: 80lm/w PF: >0.9 Led: SMD2835 Led Quantity: 300 leds	3000K	38W	CE & RoHS, 3 years warranty
	614*614MM Welding Frame Light	Product Size: 614x614x10 MM FRAME: White Diffuser: PC Driver:Customer provide Input Voltage: AC220-240V Ra: >80 Luminous Efficacy: 80lm/w PF: >0.9 Led: SMD2835 Led Quantity: 300 leds	4000K	38W	CE&Rohs 3 years YEARS
	1240*648mm Frame Light	Length: 1248,00 mm Width: 648,00 mm Height: 25,00 mm housing material: Aluminium/PC IP44 Dimmable: Y Light Power in Watt: 74 Real Power Consumption in Watt: 74 Kelvin: 1900K - 4000K Beam Angle: 120?Lumen: 4950 Voltage: 220 - 240V AC CRI: 92	1900K-4000K	74W	YEARS
	948*648mm Frame Light	Length: 948,00 mm Width: 648,00 mm Height: 25,00 mm housing material: Aluminium/PC IP44 Dimmable: Y Light Power in Watt: 62 Real Power Consumption in Watt: 62 Kelvin: 1900K - 4000K Beam Angle: 120?Lumen: 4150 Voltage: 220 - 240V AC CRI: 92	1900K-4000K	62W	YEARS
	1556*648mm Frame Light	Length: 1556,00 mm Width: 648,00 mm Height: 25,00 mm housing material: Aluminium/PC IP44 Dimmable: Y Light Power in Watt: 86 Real Power Consumption in Watt: 86 Kelvin: 1900K - 4000K Beam Angle: 120?Lumen: 5750 Voltage: 220 - 240V AC CRI: 92	1900K-4000K	86W	YEARS
