Constant current independent dimmable driver BK-DKLXXX Series (DALI-2+pushDIM)
Product Introduction
- Support DALI-2+pushDIM dimming mode
- Multi-level current output can be realized by DIP-switch
-- Soft dimming and flicker-free at any brightness
- IP20 protection grade, indoor use
- High PF, high efficiency, low THD
- Suitable for built-in use of Class I lamps
- Nominal life-time up to 100,000 h
- 5-year guarantee
- Compliance with CE,ENEC,UKCA,RCM,CCC,DALI-2,EL and other certifications
Product Downloads
Overview
Model | Output power | Output current | Input voltage | Output voltage | Dimension |
| 100W MAX | 0.225-0.6A | 200-240VAC/DC | 24-42VDC | L117*W45.5*H29mm |
BK-DKL040-A1050AD | 150W MAX | 0.6-1.05A | 200-240VAC/DC | 24-42VDC | L137*W46*H30mm |
BK-DKL060-A1650AD | 199.2W MAX. | 1.1-1.65A | 200-240VAC/DC | 24-42VDC | L157.5*W50.5*H30mm |
