Dimmable & Flicker free LED Driver for Panel Light US-standard LF-GMDXXX series
Product Introduction
Features
Conforms to the latest safety standards: the output circuit is isolated from the dimming circuit
Conforms to the latest DLC5.0 certification standards
Upgraded dimming effect: the dimming curve becomes much smoother; the light can be dimmedtooff;
up to 10 pieces of LED drivers to be turned on and off synchronously
Product Downloads
Overview
Model | SPECIFICATION | CERTIFICATE |
LF-GMD045YSV | AC100-277V DC25-42V 800-1100mA 40W | UL, FCC, Class P |
LF-GMD035YSV | AC100-277V DC25-42V 550-800mA 30W | UL, FCC, Class P |
LF-GMD065YSV | AC100-277V DC25-42V 60W | UL, FCC, Class P |
Safety Standard | UL8750, AS/NZS 61347-1: | |
"Working Temperature:-20℃ - +45℃ Working Humidity:20-90%RH (no condensation) Storage Temperature/Humidity:-30℃ - 80℃ (six months under class I environment); 10-90%RH (no condensation) Atmospheric Pressure:86kPa~106kPa" | ||
